Reflective
Harnesses sunlight instead of fighting it. Color without light emission.
Energy only on refresh — holding an image costs nothing.
Pigmented
digital tiles
Print-depth reflective color. 4× LED daylight contrast. 99% fill. 650k colors. 0.5s refresh.
Pigmented pixel tech
How it works
Patented electro-hydraulic control with auto-correction drives vivid 0.5s color changes.
Main Properties
Digital
0.5s refresh. Works with standard digital-signage networks.
Print-quality color
HP-scale color conversion. Special effects included.
Contrast
4× better than LED in daylight. HP-grade print look.
Fill factor
99%
Modular
15×15 cm tiles. Any display size. Flexible pixel pitch.
The Tile
A modular basic building block
Technical specification
- Current tile can consist of 10 or 16 mm pitch pixels.
- 44 tiles make 1 square meter of display.
- The open architecture enables any size and color.
Power Consumption10 W (at 6 frames/min)/sqm
Working Voltage110/220 V (AC)
Weight90 Kg/sqm
Primary ColorsCyan, Yellow, Magenta, Black
Pixel Size10 or 16 mm pitch
Color Depth~650,000 Colors
Color QualityPrint, HP colors
Viewing Angle180° Horizontally and vertically
Fill Factor99%
Environmental RatingNEMA 4/IP65, sealed/Water proof
Refresh Rate0.5 Sec.
Working Temperature-20° up to +80° C
Life5 Years
Physical properties
- IP65 · waterproof · self-temp regulation
- Plug-and-play multi-tile configs
- Low energy · solar off-grid
- Anti-UV / anti-reflection coating
- Auto color correction
- Any size from 15×15 cm tiles
